0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip

0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip

    • 0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip
    • 0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip
  • 0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip

    Product Details:

    Place of Origin: China (mainland)
    Brand Name: Double Light
    Certification: ISO9001:2008,ROHS
    Model Number: DL-TOP2835IRC-1500

    Payment & Shipping Terms:

    Minimum Order Quantity: 10,000pcs
    Packaging Details: Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms
    Delivery Time: 5-7 working days after received your payment
    Payment Terms: Telegraphic Transfer in Advance (Advance TT, T/T)
    Supply Ability: 15,000,000pcs per Day
    Contact Now
    Detailed Product Description
    Product Name: 1500nm Infrared LEDs Diameter: 2835 SMD LED Infrared
    Emitted Color: SMD Infrared LED Peak Emission Wavelength: 1500nm
    Chip Material: GaAlAs Lens Type: Water Clear
    Forward Voltage @20ma: 0.7-1v Viewing Angle: 120 Deg



    0.75Mm Height Top View 2835 Infrared Emitting Diode , 1500nm Infrared LED Chip

    • Features:
    1. P-LCC-2 package.
    2. White package.
    3. Optical indicator.
    4. Colorless clear window.
    5. Ideal for backlight and light pipe application.
    6. Inter reflector.
    7. Wide viewing angle.
    8. Suitable for automatic placement equipment.
    9. Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
    10. Available on tape and reel (8mm Tape).
    11. The product itself will remain within RoHS compliant Version.
    • Descriptions:
    1. The 2835 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.
    • Applications:
    1. Automotive: Backlighting in dashboards and switches.
    2. Telecommunication: Indicator and backlight in telephone and fax
    3. Indicator and backlight for audio and video equipment.
    4. Indicator and backlight in office and family equipment.
    5. Flat backlight for LCD’s, switches and symbols.
    6. Light pipe application.
    7. General use.
    • Absolute Maximum Ratings at Ta=25℃
    Parameters Symbol Min. Typ. Max. Unit Test Condition
    Radiant Intensity * Ee 2.5 5.0 --- mW/sr IF=20mA
    Viewing Angle * 2θ 1/2 --- 120 --- Deg IF=20mA (Note 2)
    Peak Emission Wavelength λp --- 1500 --- nm IF=20mA (Note 3)
    Spectral Bandwidth △λ --- 1525 --- nm IF=20mA
    Forward Voltage VF 0.70 0.85 1.00 V IF=20mA
    Reverse Current IR --- --- 2 µA VR=5V




    Notes:

    Luminous (Radiant) Intensity Measurement allowance is ± 10%. θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity. The dominant wavelength (λp) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
    Parameters Symbol Max. Unit
    Power Dissipation PD 95 mW

    Peak Forward Current

    (1/10 Duty Cycle, 0.1ms Pulse Width)

    IFP 150 A
    Forward Current IF 100 mA
    Reverse Voltage VR 5 V
    Operating Temperature Range Topr -40℃ to +80℃
    Storage Temperature Range Tstg -40℃ to +85℃
    Lead Soldering Temperature Tsld 260℃ for 5 Seconds
