Product Name: 7 Segment LED Display Package: 0.5 Inch
Emitted Color: Super Bright Red Peak Emission Wavelength: 640nm
Chip Material: GaAlAs Face Color: Black Surface
Forward Voltage @20ma: 1.8V Luminous Intensity: 28-55mcd
Description: Common Cathode



Countdown Timer Dual Digits Alpha Numeric 14 Segment Led Display Single Color Common Cathode Anode​​

  • Features:
  1. 0.50″(inch) digit height.
  2. Excellent segment uniformity.
  3. Sold state reliability.
  4. Industrial standard size.
  5. Low power consumption.
  6. The product itself will remain within RoHS compliant Version.
  • Descriptions:
  1. The DLA1-501XRB series is a lager 12.7mm(0.50″) high seven segments display designed for viewing distances up to 7 meters.
  2. These displays provide excellent reliability in bright ambient light.
  3. These devices are made with white segments and black surface.
  • Applications:
  1. Audio equipment.
  2. Instrument panels.
  3. Digital read out display.



Model No. Chip Material Source Color Description
DLA2-502CRB GaAlAs Super Bright Red Common Cathode




  • Absolute Maximum Ratings at Ta=25℃
Parameters Symbol Max. Unit
Power Dissipation Per Segment PD 100 mW

Peak Forward Current Per Segment

(1/10 Duty Cycle, 0.1ms Pulse Width)

IFP 100 mA
Forward Current Per Segment IF 20 mA
Dating Linear From 50℃   0.4 mA/℃
Reverse Voltage VR 5 V
Operating Temperature Range Topr -40℃ to +80℃
Storage Temperature Range Tstg -40℃ to +85℃
Soldering Temperature Tsld 260℃ for 5 Seconds




  • Electrical Optical Characteristics at Ta=25℃
Parameters Symbol Min. Typ. Max. Unit Test Condition
Luminous Intensity Iv 28 55 --- mcd IF=20mA (Note 1)
Luminous Intensity Matching Ratio (Segment To Segment) Iv-m --- --- 2:1   IF=10mA
Peak Emission Wavelength λp --- 640 --- nm IF=20mA
Dominant Wavelength λd --- 630 --- nm IF=20mA (Note 2)
Spectral Line Half-Width △λ --- 20 --- nm IF=20mA
Forward Voltage VF --- 1.80 2.40 V IF=20mA
Reverse Current IR --- --- 50 µA VR=5V




Notes:

Luminous intensity is measured with a light sensor and filter combination that approximates the CIE eye-response curve. The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
