| Product Name: | High Power 3535 White LED In Pcb Board | Emitted Color: | White Color LED |
|---|---|---|---|
| Test Condition: | IF=350/700ma | Viewing Angle: | 90 Deg |
| Luminous Flux: | 220lm (IF=700ma) | Forward Voltage: | 2.8-3.8v |
| Chip Material: | InGaN | Color Temperature: | 5500-6500K |
| High Light: | brightest smd led chip,led smd chip |
||
High Power 3535 3030 1W 3W 10W LED Chip White LED Light Components in pcb board
Absolute Maximum Ratings at Ta=25℃
| Parameters | Symbol | Rating | Units |
| Forward Current | IF | 350 | mA |
| Power Dissipation | PD | 3000 | mW |
| Reverse Voltage | VR | 5 | V |
| Electrostatic Discharge (HBM) | ESD | 1000 | V |
| Operating Temperature Range | Topr | -10 to +70 | ℃ |
| Storage Temperature Range | Tstg | -20 to +80 | ℃ |
| Soldering Time at 260 ℃ (Max.) | Tsol | 5 | Seconds |
Notes:
1. Proper current derating must be observed to maintain junction temperature below the maximum.
2. LEDs are not designed to be driven in reserve bias.
Electrical Optical Characteristics at Ta=25℃
| Parameters | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
| Viewing Angle [1] | 2θ1/2 | --- | 90 | -- | Deg | IF=350mA |
| Forward Voltage [2] | VF | 2.8 | 3.4 | 3.8 | V | IF=350mA |
| Reverse Current | IR | --- | --- | 10 | µA | VR=5V |
| Color Temperature | TC | 5500 | --- | 6500 | nm | IF=350mA |
| Luminous Flux | Фv | 100 | 120 | 130 | lm | IF=350mA |
Notes:
1. 2θ1/2 is the off axis angle from lamp centerline where the luminous intensity is 1/2 of the peak value. 2. Forward Voltage measurement tolerance: ±0.1V
